Integrated manual turntable - PL900
Option turntable integrated into the table diameter 800 mm.
This manual turntable is used to facilitate the handling of heavy or bulky parts inside the machine during sandblasting.
Our options are manufactured on demand
Contact us to discuss your project and obtain a personalised quotation and lead time.
Description of the integrated manual turntable for sandblasting and dust removal booths
The PL900 turntable is a piece of equipment specially designed and manufactured by our teams in our Lille workshop to support and facilitate the handling of heavy parts during surface treatment in sandblasting booths or manual dust removal booths.
The turntable allows 360° rotation in the booth in an environment containing abrasives and dust.
Its robust and reliable design enables it to withstand intensive sandblasting environments and sleeve cabinet operations generating significant flows of dust, large impurities and high-intensity abrasive projections.
The turntable's rotational movement has been designed to withstand very dusty environments and the presence of abrasives thanks to suitable materials such as double-sealed bearings.
PL 900 turntable nomenclature
.jpg)
- Manual turntable integrated into the work table
- Diameter: Ø800 (fixed diameter that does not vary depending on the width of the cabin)
- Double-sealed ball bearings
- Perforated sheet metal: thickness 3 mm, hole Ø3 mm
- Maximum load capacity: 500 kg
- The PL900 turntable is directly integrated into the CHAR 3 loading trolley option
| Type & cabine | Weight of option | Position on the table |
| Cabine 1000 | 50 kg | Centered |
| Cabine 1250 | 75 kg | Centered |
| Cabine 1500 | 65 kg | Off-centered to be in front of opérator hands |
| Loarding trolley CHAR 3 | 125 kg | Centered |
Removable turntable - PL450
If you would like a smaller, removable turntable for your surface treatment in a sandblasting cabinet, we have also designed the PL405.
Its Ø500 mm diameter and removable design allow it to be easily inserted into or removed from the sandblasting or dust removal cabinet.
Discover this option by clicking on the image on the right.
PL900
Specific References
Other options and accessories available
As a machine designer and manufacturer, we can adapt each production to your needs. The list of options and accessories presented on our website is indicative only.
Don't hesitate to contact us with your project to start a study with our engineer for a tailor-made design.
All our machines, options and accessories are designed and manufactured in our factory in Northern France.
