Sandblasting cabinets from the EXPERT RANGE can be equipped with two different system of abrasive blasting :
Suction (DF code) | Pressure (PF code) |
---|---|
Easy to use with simple settings and maintenance, this system use the Venturi effect. It will correspond to application with less intensive needs, such as glass beads blasting .
It is a system that allows the use of multi nozzle on the same tank. |
The abrasif is blasted from the tank which is pressurized. This system enables much higher abrasive blasting rates than suction.
With more efficient, intensive and powerful use, pressure blasting offers yields that are 3 to 5 times higher. |
OVERALL DESCRIPTION
· Cabin equipped with a tungsten carbide (suction range) or boron carbide (pressure range) blasting nozzle and a air blow nozzle. Separate pedal controls.
· High-performance, compact, integrated suction and ventilation system with triple module and side-channel turbine at the rear of each cabinet.
· Multiple settings and easy maintenance:
o Pressure gauge for adjusting blasting pressure between 0 and 8 bar
o Air flow adapted to abrasive grain size to facilitate separation of abrasive and dust
o Machine height (3 height adjustments over 100 mm except for PF700)
o Filter cartridge cleaning pressure
· Reinforced cab with hoops and lifting rings. .
· Quick, intuitive replacement of wearing parts (gloves, glass, filters, nozzles, etc.).
100% of spare parts are available from stock, with shipment within 24-48 hours.
DETAILS
Filter cartridge change |
Filter cleaning pressure gauge |
Sandblasting cabinet work grate |
Glass replacement |
Pressure blasting nozzle and blowgun |
Coarse dirt retention sieve |
CHOICE OF THE DIAMETER OF THE NOZZLE ACCORDING TO COMPRESSOR |
||||||
RANGE EXPERT PF ( overpressure) : * |
||||||
Power of the compressor |
10 Ch / 7,5 Kw |
15 Ch / 11 Kw |
20 Ch / 15 Kw |
|||
Ø inside buzzard |
4 mm |
5 mm |
6 mm |
|||
Consumption of air (for P=6 bar) |
50 M3/h |
80 M3/h |
120 M3/h |
|||
RANGE EXPERT DF (system At depression) * |
||||||
Minimum Required Reciprocating Compressor Power |
3 Ch / 2,2 Kw |
10 Ch / 7,5 Kw |
15 Ch / 11 Kw |
|||
Minimum required power of the screw compressor |
3 Ch / 2,2 Kw |
7,5 Ch / 5,5 Kw |
10 Ch / 7,5 Kw |
|||
Ø Inside nozzle |
5 mm |
6 mm |
8 mm |
|||
Air consumption (for P=6 bar) |
12 M3/h |
27 M3/h |
48 M3/h |
|||
*Outside Consumption Cumulative some Other machinery Connected At your network of air tablet.
To from guarantee some Performance Optimal from the machine you Must you insure some Good Diameters from Pipes all the long from your installation.
Also discover our other sandblasting machines
Since 1979 All our cabins are Designed and manufactured in our workshop in the north of France.
